TSUBAKI ANSI BL flyerkettingen
TSUBAKI ANSI BL flyerkettingen
Leaf Chain is de meest eenvoudige stalen ketting, die alleen bestaat uit schakelplaten en pinnen. Deze ketting heeft over het algemeen een grotere treksterkte dan rollenkettingen en loopt over schijven in plaats van tandwielen. Ze zijn geschikt voor hangende, balancerende of bewegingsoverbrengende toepassingen. Bladkettingen worden vaak gebruikt als contragewichtkettingen voor werktuigmachines, lift- en ovendeuren, vorkheftruckmasten, draaiende frames en soortgelijke hef- of balanceertoepassingen.
2×2 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL422 | 12.70 | 1/2″ | 2×2 |
| BL522 | 15.875 | 5/8″ | 2×2 |
| BL622 | 19.05 | 3/4″ | 2×2 |
| BL822 | 25.40 | 1″ | 2×2 |
| BL1022 | 31.75 | 1 1/4″ | 2×2 |
| BL1222 | 38.10 | 1 1/2″ | 2×2 |
| BL1422 | 44.45 | 1 3/4″ | 2×2 |
| BL1622 | 50.80 | 2″ | 2×2 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL422 | 5.08 | 5.44 | 6.99 | 2.00 | 12.00 | 5.13 | 23.5 | 0.68 |
| BL522 | 5.94 | 6.32 | 8.23 | 2.40 | 15.00 | 6.00 | 39.2 | 1.07 |
| BL622 | 7.90 | 8.20 | 11.02 | 3.20 | 18.10 | 7.97 | 63.7 | 1.68 |
| BL822 | 9.48 | 10.08 | 13.28 | 4.00 | 24.10 | 9.57 | 103.0 | 2.59 |
| BL1022 | 11.04 | 11.99 | 15.67 | 4.80 | 30.10 | 11.14 | 141.0 | 3.76 |
| BL1222 | 12.64 | 14.02 | 18.54 | 5.60 | 36.20 | 12.74 | 186.0 | 4.83 |
| BL1422 | 14.21 | 15.82 | 20.83 | 6.40 | 42.20 | 14.32 | 235.0 | 7.31 |
| BL1622 | 17.38 | 17.81 | 24.41 | 7.20 | 48.20 | 17.49 | 353.0 | 9.84 |
2×3 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL423 | 12.70 | 1/2″ | 2×3 |
| BL523 | 15.875 | 5/8″ | 2×3 |
| BL623 | 19.05 | 3/4″ | 2×3 |
| BL823 | 25.40 | 1″ | 2×3 |
| BL1023 | 31.75 | 1 1/4″ | 2×3 |
| BL1223 | 38.10 | 1 1/2″ | 2×3 |
| BL1423 | 44.45 | 1 3/4″ | 2×3 |
| BL1623 | 50.80 | 2″ | 2×3 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL423 | 5.08 | 6.48 | 8.02 | 2.00 | 12.00 | 5.13 | 23.5 | 0.84 |
| BL523 | 5.94 | 7.55 | 9.45 | 2.40 | 15.00 | 6.00 | 39.2 | 1.27 |
| BL623 | 7.90 | 9.88 | 12.67 | 3.20 | 18.10 | 7.97 | 63.7 | 2.04 |
| BL823 | 9.48 | 12.10 | 15.30 | 4.00 | 24.10 | 9.57 | 103.0 | 3.20 |
| BL1023 | 11.04 | 14.45 | 18.15 | 4.80 | 30.10 | 11.14 | 141.0 | 4.69 |
| BL1223 | 12.64 | 16.95 | 21.45 | 5.60 | 36.20 | 12.74 | 186.0 | 6.54 |
| BL1423 | 14.21 | 19.10 | 24.10 | 6.40 | 42.20 | 14.32 | 235.0 | 9.06 |
| BL1623 | 17.38 | 21.63 | 28.22 | 7.20 | 48.20 | 17.49 | 353.0 | 12.16 |
3×4 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL434 | 12.70 | 1/2″ | 3×4 |
| BL534 | 15.875 | 5/8″ | 3×4 |
| BL634 | 19.05 | 3/4″ | 3×4 |
| BL834 | 25.40 | 1″ | 3×4 |
| BL1034 | 31.75 | 1 1/4″ | 3×4 |
| BL1234 | 38.10 | 1 1/2″ | 3×4 |
| BL1434 | 44.45 | 1 3/4″ | 3×4 |
| BL1634 | 50.80 | 2″ | 3×4 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL434 | 5.08 | 8.61 | 10.15 | 2.00 | 12.00 | 5.13 | 35.3 | 1.13 |
| BL534 | 5.94 | 10.05 | 11.95 | 2.40 | 15.00 | 6.00 | 58.8 | 1.69 |
| BL634 | 7.90 | 13.23 | 16.02 | 3.20 | 18.10 | 7.97 | 95.6 | 2.83 |
| BL834 | 9.48 | 16.28 | 19.47 | 4.00 | 24.10 | 9.57 | 155.7 | 4.44 |
| BL1034 | 11.04 | 19.43 | 23.12 | 4.80 | 30.10 | 11.14 | 216.0 | 6.55 |
| BL1234 | 12.64 | 22.75 | 27.25 | 5.60 | 36.20 | 12.74 | 299.0 | 9.10 |
| BL1434 | 14.21 | 25.70 | 30.70 | 6.40 | 42.20 | 14.32 | 387.0 | 11.32 |
| BL1634 | 17.38 | 29.20 | 35.80 | 7.20 | 48.20 | 17.49 | 554.0 | 16.95 |
4×4 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL444 | 12.70 | 1/2″ | 4×4 |
| BL544 | 15.875 | 5/8″ | 4×4 |
| BL644 | 19.05 | 3/4″ | 4×4 |
| BL844 | 25.40 | 1″ | 4×4 |
| BL1044 | 31.75 | 1 1/4″ | 4×4 |
| BL1244 | 38.10 | 1 1/2″ | 4×4 |
| BL1444 | 44.45 | 1 3/4″ | 4×4 |
| BL1644 | 50.80 | 2″ | 4×4 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL444 | 5.08 | 9.70 | 11.25 | 2.00 | 12.00 | 5.13 | 47.1 | 1.28 |
| BL544 | 5.94 | 11.28 | 13.18 | 2.40 | 15.00 | 6.00 | 78.5 | 1.89 |
| BL644 | 7.90 | 14.91 | 17.70 | 3.20 | 18.10 | 7.97 | 127.0 | 3.18 |
| BL844 | 9.48 | 18.47 | 21.67 | 4.00 | 24.10 | 9.57 | 206.0 | 5.04 |
| BL1044 | 11.04 | 21.69 | 25.37 | 4.80 | 30.10 | 11.14 | 282.0 | 7.48 |
| BL1244 | 12.64 | 25.65 | 30.18 | 5.60 | 36.20 | 12.74 | 373.0 | 10.39 |
| BL1444 | 14.21 | 29.03 | 34.04 | 6.40 | 42.20 | 14.32 | 471.0 | 12.96 |
| BL1644 | 17.38 | 32.94 | 39.55 | 7.20 | 48.20 | 17.49 | 706.0 | 18.97 |
4×6 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL446 | 12.70 | 1/2″ | 4×6 |
| BL546 | 15.875 | 5/8″ | 4×6 |
| BL646 | 19.05 | 3/4″ | 4×6 |
| BL846 | 25.40 | 1″ | 4×6 |
| BL1046 | 31.75 | 1 1/4″ | 4×6 |
| BL1462 | 38.10 | 1 1/2″ | 4×6 |
| BL1446 | 44.45 | 1 3/4″ | 4×6 |
| BL1646 | 50.80 | 2″ | 4×6 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL446 | 5.08 | 11.80 | 13.35 | 2.00 | 12.00 | 5.13 | 47.1 | 1.65 |
| BL546 | 5.94 | 13.75 | 15.65 | 2.40 | 15.00 | 6.00 | 78.5 | 2.40 |
| BL646 | 7.90 | 18.25 | 21.05 | 3.20 | 18.10 | 7.97 | 127.0 | 4.01 |
| BL846 | 9.48 | 22.50 | 25.70 | 4.00 | 24.10 | 9.57 | 206.0 | 6.32 |
| BL1046 | 11.04 | 26.85 | 30.55 | 4.80 | 30.10 | 11.14 | 282.0 | 9.29 |
| BL1246 | 12.64 | 31.48 | 35.97 | 5.60 | 36.20 | 12.74 | 373.0 | 12.01 |
| BL1446 | 14.21 | 35.63 | 40.62 | 6.40 | 42.20 | 14.32 | 471.0 | 18.00 |
| BL1646 | 17.38 | 40.53 | 47.12 | 7.20 | 48.20 | 17.49 | 706.0 | 24.09 |
6×6 Lacing Details
| Tsubaki Chain No. | Pitch p | Lacing Combination LC | |
|---|---|---|---|
| BL466 | 12.70 | 1/2″ | 6×6 |
| BL566 | 15.875 | 5/8″ | 6×6 |
| BL666 | 19.05 | 3/4″ | 6×6 |
| BL866 | 25.40 | 1″ | 6×6 |
| BL1066 | 31.75 | 1 1/4″ | 6×6 |
| BL1266 | 38.10 | 1 1/2″ | 6×6 |
| BL1466 | 44.45 | 1 3/4″ | 6×6 |
| BL1666 | 50.80 | 2″ | 6×6 |
| Tsubaki Chain No. | Pin | Link Plate | Min. Tensile Strength acc. to Tsubaki kN | Approx. Mass kg/m | ||||
|---|---|---|---|---|---|---|---|---|
| Diameter d2 | Length L1 | Length L2 | Thickness T | Height H (max.) | Hole Diameter d4 | |||
| BL466 | 5.08 | 13.89 | 15.44 | 2.00 | 12.00 | 5.13 | 69.4 | 1.96 |
| BL566 | 5.94 | 16.23 | 18.14 | 2.40 | 15.00 | 6.00 | 117.4 | 2.80 |
| BL666 | 7.90 | 21.62 | 24.41 | 3.20 | 18.10 | 7.97 | 191.2 | 4.73 |
| BL866 | 9.48 | 26.64 | 29.85 | 4.00 | 24.10 | 9.57 | 309.0 | 7.54 |
| BL1066 | 11.04 | 31.93 | 35.61 | 4.80 | 30.10 | 11.14 | 424.0 | 11.16 |
| BL1266 | 12.64 | 37.29 | 41.81 | 5.60 | 36.20 | 12.74 | 559.0 | 14.58 |
| BL1466 | 14.21 | 42.24 | 47.24 | 6.40 | 42.20 | 14.32 | 706.0 | 22.51 |
| BL1666 | 17.38 | 48.08 | 54.69 | 7.20 | 48.20 | 17.49 | 1060.0 | 28.73 |
